Number of process chambers:

Up to 5 process chambers

§

Process chamber type:

Sputter & Degas & Pre-clean & Evaporation

§

Load-Lock:

2 Separate Load-Lock Chambers

§

Transfer chamber:

Integrated BROOKS System

§

Ion source:

DC/RF Ion Source

§

Pumping system:

Cryopump/Magnetic suspension molecular pump + Dry pump

§

Vacuum gauge:

Full range vacuum gauge + Capacitive diaphragm vacuum gauge

§

Flow control:

Mass flow controller

§

Ultimate vacuum:

1E-5Pa

§

Temperature control range:

-80℃ to 500℃

§

Uniform deposition area:

?200mm

§

Coating uniformity:

±2%

§

Space requirements:

Customized according to demand
